LabGard NU-677 Class II Type A2 Biosafety Cabinet
The NU-677 is tailor-made for work in a vivarium by integrating an NSF-listed 12” (305mm) work access opening for cage access, castors and pull bars for mobility, and height adjustability for user ergonomics.
- Overview
- Specifications
- Reviews
- Resources
- Options
Overview
The NU-677 is tailor-made for work in a vivarium by integrating an NSF-listed 12” (305mm) work access opening for cage access, castors and pull bars for mobility, and height adjustability for user ergonomics. This design also rises to the unique challenges of controlling airflow in a particulate-heavy environment. An accessible pre-filter in the back wall prescreens larger contaminants to protect the main HEPA filters. The DC ECM motor economizes energy and evenly distributes laminar downflow through a flexible plenum and provides enough power to overcome HEPA filter saturation. The work zone side and back walls are constructed from stainless steel for easy cleanability and surround a unified, flat work surface. Users can adjust the cabinet’s height at the press of a button and easily monitor cabinet performance through the Aeromax™ control system that visualizes pressure in the cabinet’s internal airflow plenum.
The NU-677 provides containment meeting the NSF/ANSI 49 standard followed in most of the Americas.
AeroMax Control System
The AeroMax control system visualizes airflow plenum pressure through a series of multicolored lights and activates both an audible and visual alarm whenever cabinet performance departs from normal parameters.
Ultra High Efficiency Motor
A single DC ECM motor with a precision-engineered forward curved fan powers airflow through the biosafety cabinet. The ultra-high efficiency motor lowers energy costs and reduces noise pollution but is powerful enough to extend filter life. The one motor design allows for easy certification and airflow balancing. In addition, it provides enough power to compensate for HEPA filter loading, reducing filter changes and lowering the total ownership cost.
Large Access Opening
An optimally sized cabinet work access opening becomes paramount in a vivarium setting, especially when handling larger rat cages or when enhanced technician maneuverability is required for smooth cage transfers. Balancing this need with stringent biohazard safety, the 12-inch (305mm) work access opening, certified to the NSF/ANSI 49 standard, stands out. It accommodates the ingress and egress of substantial cages and provides ample space for technicians' arms, facilitating efficient and secure operations without compromising on containment.
Back Wall Pre-filter
In a vivarium, the longevity of a biosafety cabinet's HEPA filters is crucial. The presence of animal hair and dander can rapidly clog standard filters, necessitating a solution tailored for such environments. This is where the reusable pre-filter comes into play, adeptly capturing larger particles and significantly extending the HEPA filter's life by allowing it to tackle finer particulates. Moreover, the pre-filter strategic placement in the cabinet's back wall simplifies maintenance, providing easy access through the work zone for hassle-free removal and cleaning. This design enhances filter efficiency and promotes a more sustainable operation.
Specifications
| Blower Contact Wires | N/A |
| Closure Panels | N/A |
| Cord Pass Through | N/A |
| Double Exhaust HEPA Filter | N/A |
| Gas Supply Interlock with Blower | N/A |
| Glass Sidewalls | N/A |
| IV Bar with 6 Hooks | N/A |
| Magnifying Glass in Window | Optional |
| Motorized Base Stand | Included |
| Motorized Window | N/A |
| Other Built-in Supply Filter Option(s) | N/A |
| Outlet(s) | Standard, two backwall |
| Plumbing | N/A |
| Remote Service Valves | N/A |
| Seismic Brackets or Studs | N/A |
| Service Couplings (3/8-inch NPT) | None, Maximum of Two Each Side Wall Optional |
| Service Valves (3/8-inch NPT) | None, Maximum of Two Each Side Wall Optional |
| Side Panels | N/A |
| Smooth Interior | N/A |
| Ultraviolet (UV) Light | Optional |
| Window Edge Protector | Optional |
| Access Opening Glass Type | Tempered Glass |
| Armrest | Standard Plastic with Optional Stainless Steel |
| Cabinet Construction | All welded stainless steel 16/18 GA, Type 304 pressure tight design |
| Casters | 5" (13mm) Casters Standard |
| Decontamination Seal-able Window | N/A |
| Diffuser | Metal, non-flammable |
| Drain Valve Location | Front right |
| Exhaust Filter | 11 1/2-inch (292 mm) 99.99% Efficiency @ 0.3 Micron |
| Front & Control Panel Material | Painted Steel |
| HEPA Filter Seal Type | HEPEX Zero Leak Neoprene Seal, Spring-loaded |
| Lighting | LED |
| Main Cabinet Wrap | Single Piece Stainless Steel Side and Back Wall Construction |
| Motor(s) | 3/4 HP DC ECM |
| Plenum Type | HEPEX |
| Pre-filter | Behind Back Wall |
| Style | Low profile console integral auto-adjustable base stand |
| Supply Filter | 3-inch (76mm) 99.99% Efficiency @ 0.3 Micron |
| Viewing Window Inches (mm) | 21 (533) open to fully closed |
| Work Access Opening(s) | 12-inch (305mm) |
| Work Surface | One-Piece Flat Stainless Steel with Prop-Up Rod |
| Work Zone Wrap | Single Piece Stainless Steel Side and Back Wall Construction |
| Data Output Features | RS-232 |
| Remote Alarm Terminals | Standard |
| Est. Shipping Depth Inches (mm) | 43 (1092) |
| Est. Shipping Height Inches (mm) | 80 (2032) |
| Est. Shipping Width Inches (mm) | 58 (1473) |
| Exterior Depth Inches (mm) | 32 1/8 (817) |
| Exterior Depth with Armrest Removed Inches (mm) | 31 3/8 (797) |
| Exterior Height (Minimum for Transport) Inches (mm) | 79 1/2 (2020) |
| Exterior Height Inches (mm) | 81 (2058)-99 1/2 (2527) |
| Exterior Height with 30-inch (762 mm) Work Surface Height inches (mm) | 81 (2058) with 24 1/2 inch (622 mm) Work Surface Height |
| Exterior Height with 36-inch (915 mm) Work Surface Height inches (mm) | 99 1/2 (2527) with 43 inch (1092 mm) Work Surface Height |
| Exterior Width Inches (mm) | 53 1/2 (1358) |
| Nominal Width Feet (Meters) | 4 ft. (1.2m) |
| Useable Work Tray Area Depth Inches (mm) | 21 3/4 (552) |
| Useable Work Tray Area Width Inches (mm) | 46 (1168) |
| Work Area Depth Measured at 10-inches (254 mm) Window Height Inches (mm) | N/A |
| Work Area Depth Measured at 12-inches (305 mm) Window Height Inches (mm) | 25 1/2 (642) |
| Work Area Depth Measured at 14-inches (356 mm) Window Height Inches (mm) | N/A |
| Work Area Depth Measured at 8-inches (203 mm) Window Height Inches (mm) | N/A |
| Work Area Height Inches (mm) | 28 1/2 (724mm) |
| Work Area Width Inches (mm) | 46 3/8 (1178) |
| Blower/Lights Amps [10-inch (254 mm) Access Opening] | |
| Blower/Lights Amps [12-inch (305 mm) Access Opening] | 6.5 |
| Blower/Lights Amps [14-inch (356mm) Access Opening] | |
| Blower/Lights Amps [8-inch (203 mm) Access Opening] | |
| Electrical Configuration | 115V60Hz |
| Junction Box | N/A |
| Outlet Amps | 3 |
| Power Cord | 12 ft. 12 GA-3 Wire, 20A |
| Power Cord Length Foot (Meter) | 12 (3.7) |
| Rated Amps | 15 |
| Light Intensity fc (Lux) | 90-120 (968-1291) |
| Reach into workzone Inches (mm) | 6 (152) |
| Sound Pressure Level per ISO 4871 | ≤ 58 dbA |
| 10-inch (254 mm) Opening Exhaust Requirement for Fixed Canopy (NU-907/NU-916) CFM (CMH) | N/A |
| 10-inch (254 mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM (CMH) | N/A |
| 12-inch (305 mm) Opening Exhaust Requirement for Fixed Canopy (NU-907/NU-916) CFM (CMH) | 526 (894) |
| 12-inch (305 mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM (CMH) | 486-656 (826-1115) |
| 14-inch (356mm) Opening Exhaust Requirement for Fixed Canopy (NU-926) CFM(CMH) | N/A |
| 14-inch (356mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM(CMH) | N/A |
| 8-inch (203 mm) Opening Exhaust Requirement for Fixed Canopy (NU-907/NU-916) CFM (CMH) | N/A |
| 8-inch (203 mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM (CMH) | N/A |
| Bag In Bag Out | N/A |
| Heat Rejected 10-inch (254 mm) Access Opening (BTU/Hour) | N/A |
| Heat Rejected 12-inch (305 mm) Access Opening (BTU/Hour) | 2551 |
| Heat Rejected 14-inch (356 mm) Access Opening (BTU/Hour) | N/A |
| Heat Rejected 8-inch (203 mm) Access Opening (BTU/Hour) | N/A |
| Heat Rejected Vented (BTU/Hour) | 157 |
| Other Built-in Exhaust Option(s) | N/A |
| Plant Duct Static Pressure Inches (mm) | 0.05-0.1"/1.27-2.54mm H2O |
| Australian Test Method | N/A |
| Performance Standard | NSF-ANSI-49 |
| Safety Certification |
| Air Cleanliness (ISO 14644) | ISO-Class-5 |
| Downflow fpm (m/s) | 60 fpm (0.30 m/s) |
| Fumigation: per NIH/NSF Procedures | True |
| Inflow fpm (m/s) | 105 fpm (0.53 m/s) |
| Protection | Product, Personnel, Environmental |
| Airflow Monitor | Pressure |
| Control System | AeroMax |
| Est. Shipping Weight lbs (kg) | 800 (362) |
| Net Weight lbs (kg) | 750 (340) |
| Blower Contact Wires | N/A |
| Closure Panels | N/A |
| Cord Pass Through | N/A |
| Double Exhaust HEPA Filter | N/A |
| Gas Supply Interlock with Blower | N/A |
| Glass Sidewalls | N/A |
| IV Bar with 6 Hooks | N/A |
| Magnifying Glass in Window | Optional |
| Motorized Base Stand | Included |
| Motorized Window | N/A |
| Other Built-in Supply Filter Option(s) | N/A |
| Outlet(s) | Standard, two backwall |
| Plumbing | N/A |
| Remote Service Valves | N/A |
| Seismic Brackets or Studs | N/A |
| Service Couplings (3/8-inch NPT) | None, Maximum of Two Each Side Wall Optional |
| Service Valves (3/8-inch NPT) | None, Maximum of Two Each Side Wall Optional |
| Side Panels | N/A |
| Smooth Interior | N/A |
| Ultraviolet (UV) Light | Optional |
| Window Edge Protector | Optional |
| Access Opening Glass Type | Tempered Glass |
| Armrest | Standard Plastic with Optional Stainless Steel |
| Cabinet Construction | All welded stainless steel 16/18 GA, Type 304 pressure tight design |
| Casters | 5" (13mm) Casters Standard |
| Decontamination Seal-able Window | N/A |
| Diffuser | Metal, non-flammable |
| Drain Valve Location | Front right |
| Exhaust Filter | 11 1/2-inch (292 mm) 99.99% Efficiency @ 0.3 Micron |
| Front & Control Panel Material | Painted Steel |
| HEPA Filter Seal Type | HEPEX Zero Leak Neoprene Seal, Spring-loaded |
| Lighting | LED |
| Main Cabinet Wrap | Single Piece Stainless Steel Side and Back Wall Construction |
| Motor(s) | 3/4 HP DC ECM |
| Plenum Type | HEPEX |
| Pre-filter | Behind Back Wall |
| Style | Low profile console integral auto-adjustable base stand |
| Supply Filter | 3-inch (76mm) 99.99% Efficiency @ 0.3 Micron |
| Viewing Window Inches (mm) | 21 (533) open to fully closed |
| Work Access Opening(s) | 12-inch (305mm) |
| Work Surface | One-Piece Flat Stainless Steel with Prop-Up Rod |
| Work Zone Wrap | Single Piece Stainless Steel Side and Back Wall Construction |
| Data Output Features | RS-232 |
| Remote Alarm Terminals | Standard |
| Est. Shipping Depth Inches (mm) | 43 (1092) |
| Est. Shipping Height Inches (mm) | 80 (2032) |
| Est. Shipping Width Inches (mm) | 58 (1473) |
| Exterior Depth Inches (mm) | 32 1/8 (817) |
| Exterior Depth with Armrest Removed Inches (mm) | 31 3/8 (797) |
| Exterior Height (Minimum for Transport) Inches (mm) | 79 1/2 (2020) |
| Exterior Height Inches (mm) | 81 (2058)-99 1/2 (2527) |
| Exterior Height with 30-inch (762 mm) Work Surface Height inches (mm) | 81 (2058) with 24 1/2 inch (622 mm) Work Surface Height |
| Exterior Height with 36-inch (915 mm) Work Surface Height inches (mm) | 99 1/2 (2527) with 43 inch (1092 mm) Work Surface Height |
| Exterior Width Inches (mm) | 53 1/2 (1358) |
| Nominal Width Feet (Meters) | 4 ft. (1.2m) |
| Useable Work Tray Area Depth Inches (mm) | 21 3/4 (552) |
| Useable Work Tray Area Width Inches (mm) | 46 (1168) |
| Work Area Depth Measured at 10-inches (254 mm) Window Height Inches (mm) | N/A |
| Work Area Depth Measured at 12-inches (305 mm) Window Height Inches (mm) | 25 1/2 (642) |
| Work Area Depth Measured at 14-inches (356 mm) Window Height Inches (mm) | N/A |
| Work Area Depth Measured at 8-inches (203 mm) Window Height Inches (mm) | N/A |
| Work Area Height Inches (mm) | 28 1/2 (724mm) |
| Work Area Width Inches (mm) | 46 3/8 (1178) |
| Blower/Lights Amps [10-inch (254 mm) Access Opening] | |
| Blower/Lights Amps [12-inch (305 mm) Access Opening] | 4.5 |
| Blower/Lights Amps [14-inch (356mm) Access Opening] | |
| Blower/Lights Amps [8-inch (203 mm) Access Opening] | |
| Electrical Configuration | 230V5060Hz |
| Junction Box | N/A |
| Outlet Amps | 3 |
| Power Cord | 12 ft., 16A |
| Power Cord Length Foot (Meter) | 12 (3.7) |
| Rated Amps | 11 |
| Light Intensity fc (Lux) | 90-120 (968-1291) |
| Reach into workzone Inches (mm) | 6 (152) |
| Sound Pressure Level per ISO 4871 | ≤ 58 dbA |
| 10-inch (254 mm) Opening Exhaust Requirement for Fixed Canopy (NU-907/NU-916) CFM (CMH) | N/A |
| 10-inch (254 mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM (CMH) | N/A |
| 12-inch (305 mm) Opening Exhaust Requirement for Fixed Canopy (NU-907/NU-916) CFM (CMH) | 526 (894) |
| 12-inch (305 mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM (CMH) | 486-656 (826-1115) |
| 14-inch (356mm) Opening Exhaust Requirement for Fixed Canopy (NU-926) CFM(CMH) | N/A |
| 14-inch (356mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM(CMH) | N/A |
| 8-inch (203 mm) Opening Exhaust Requirement for Fixed Canopy (NU-907/NU-916) CFM (CMH) | N/A |
| 8-inch (203 mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM (CMH) | N/A |
| Bag In Bag Out | N/A |
| Heat Rejected 10-inch (254 mm) Access Opening (BTU/Hour) | N/A |
| Heat Rejected 12-inch (305 mm) Access Opening (BTU/Hour) | 3530 |
| Heat Rejected 14-inch (356 mm) Access Opening (BTU/Hour) | N/A |
| Heat Rejected 8-inch (203 mm) Access Opening (BTU/Hour) | N/A |
| Heat Rejected Vented (BTU/Hour) | Inquire |
| Other Built-in Exhaust Option(s) | N/A |
| Plant Duct Static Pressure Inches (mm) | 0.05-0.1"/1.27-2.54mm H2O |
| Australian Test Method | N/A |
| Performance Standard | |
| Safety Certification |
| Air Cleanliness (ISO 14644) | ISO-Class-5 |
| Downflow fpm (m/s) | 60 fpm (0.30 m/s) |
| Fumigation: per NIH/NSF Procedures | True |
| Inflow fpm (m/s) | 105 fpm (0.53 m/s) |
| Protection | Product, Personnel, Environmental |
| Airflow Monitor | Pressure |
| Control System | AeroMax |
| Est. Shipping Weight lbs (kg) | 800 (362) |
| Net Weight lbs (kg) | 750 (340) |
| Blower Contact Wires | N/A |
| Closure Panels | N/A |
| Cord Pass Through | N/A |
| Double Exhaust HEPA Filter | N/A |
| Gas Supply Interlock with Blower | N/A |
| Glass Sidewalls | N/A |
| IV Bar with 6 Hooks | N/A |
| Magnifying Glass in Window | Optional |
| Motorized Base Stand | Included |
| Motorized Window | N/A |
| Other Built-in Supply Filter Option(s) | N/A |
| Outlet(s) | Standard, two backwall |
| Plumbing | N/A |
| Remote Service Valves | N/A |
| Seismic Brackets or Studs | N/A |
| Service Couplings (3/8-inch NPT) | None, Maximum of Two Each Side Wall Optional |
| Service Valves (3/8-inch NPT) | None, Maximum of Two Each Side Wall Optional |
| Side Panels | N/A |
| Smooth Interior | N/A |
| Ultraviolet (UV) Light | Optional |
| Window Edge Protector | Optional |
| Access Opening Glass Type | Tempered Glass |
| Armrest | Standard Plastic with Optional Stainless Steel |
| Cabinet Construction | All welded stainless steel 16/18 GA, Type 304 pressure tight design |
| Casters | 5" (13mm) Casters Standard |
| Decontamination Seal-able Window | N/A |
| Diffuser | Metal, non-flammable |
| Drain Valve Location | Front right |
| Exhaust Filter | 11 1/2-inch (292 mm) 99.99% Efficiency @ 0.3 Micron |
| Front & Control Panel Material | Painted Steel |
| HEPA Filter Seal Type | HEPEX Zero Leak Neoprene Seal, Spring-loaded |
| Lighting | LED |
| Main Cabinet Wrap | Single Piece Stainless Steel Side and Back Wall Construction |
| Motor(s) | 1 HP DC ECM |
| Plenum Type | HEPEX |
| Pre-filter | Behind Back Wall |
| Style | Low profile console integral auto-adjustable base stand |
| Supply Filter | 3-inch (76mm) 99.99% Efficiency @ 0.3 Micron |
| Viewing Window Inches (mm) | 21 (533) open to fully closed |
| Work Access Opening(s) | 12-inch (305mm) |
| Work Surface | One-Piece Flat Stainless Steel with Prop-Up Rod |
| Work Zone Wrap | Single Piece Stainless Steel Side and Back Wall Construction |
| Data Output Features | RS-232 |
| Remote Alarm Terminals | Standard |
| Est. Shipping Depth Inches (mm) | 43 (1092) |
| Est. Shipping Height Inches (mm) | 75 (1905) |
| Est. Shipping Width Inches (mm) | 70 (1778) |
| Exterior Depth Inches (mm) | 32 1/8 (817) |
| Exterior Depth with Armrest Removed Inches (mm) | 31 3/8 (797) |
| Exterior Height (Minimum for Transport) Inches (mm) | 79 1/2 (2020) |
| Exterior Height Inches (mm) | 81 (2058)-99 1/2 (2527) |
| Exterior Height with 30-inch (762 mm) Work Surface Height inches (mm) | 81 (2058) with 24 1/2 inch (622 mm) Work Surface Height |
| Exterior Height with 36-inch (915 mm) Work Surface Height inches (mm) | 99 1/2 (2527) with 43 inch (1092 mm) Work Surface Height |
| Exterior Width Inches (mm) | 65 1/2 (1663) |
| Nominal Width Feet (Meters) | 5 ft. (1.5m) |
| Useable Work Tray Area Depth Inches (mm) | 21 3/4 (552) |
| Useable Work Tray Area Width Inches (mm) | 58 (1473) |
| Work Area Depth Measured at 10-inches (254 mm) Window Height Inches (mm) | N/A |
| Work Area Depth Measured at 12-inches (305 mm) Window Height Inches (mm) | 25 1/2 (642) |
| Work Area Depth Measured at 14-inches (356 mm) Window Height Inches (mm) | N/A |
| Work Area Depth Measured at 8-inches (203 mm) Window Height Inches (mm) | N/A |
| Work Area Height Inches (mm) | 28 1/2 (724mm) |
| Work Area Width Inches (mm) | 58 3/8 (1483) |
| Blower/Lights Amps [10-inch (254 mm) Access Opening] | |
| Blower/Lights Amps [12-inch (305 mm) Access Opening] | 6.8 |
| Blower/Lights Amps [14-inch (356mm) Access Opening] | |
| Blower/Lights Amps [8-inch (203 mm) Access Opening] | |
| Electrical Configuration | 115V60Hz |
| Junction Box | N/A |
| Outlet Amps | 3 |
| Power Cord | 12 ft. 12 GA-3 Wire, 20A |
| Power Cord Length Foot (Meter) | 12 (3.7) |
| Rated Amps | 16 |
| Light Intensity fc (Lux) | 90-120 (968-1291) |
| Reach into workzone Inches (mm) | 6 (152) |
| Sound Pressure Level per ISO 4871 | ≤ 60 dbA |
| 10-inch (254 mm) Opening Exhaust Requirement for Fixed Canopy (NU-907/NU-916) CFM (CMH) | N/A |
| 10-inch (254 mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM (CMH) | N/A |
| 12-inch (305 mm) Opening Exhaust Requirement for Fixed Canopy (NU-907/NU-916) CFM (CMH) | 659 (1120) |
| 12-inch (305 mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM (CMH) | 611-761 (1038-1294) |
| 14-inch (356mm) Opening Exhaust Requirement for Fixed Canopy (NU-926) CFM(CMH) | N/A |
| 14-inch (356mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM(CMH) | N/A |
| 8-inch (203 mm) Opening Exhaust Requirement for Fixed Canopy (NU-907/NU-916) CFM (CMH) | N/A |
| 8-inch (203 mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM (CMH) | N/A |
| Bag In Bag Out | N/A |
| Heat Rejected 10-inch (254 mm) Access Opening (BTU/Hour) | N/A |
| Heat Rejected 12-inch (305 mm) Access Opening (BTU/Hour) | 2669 |
| Heat Rejected 14-inch (356 mm) Access Opening (BTU/Hour) | N/A |
| Heat Rejected 8-inch (203 mm) Access Opening (BTU/Hour) | N/A |
| Heat Rejected Vented (BTU/Hour) | 178 |
| Other Built-in Exhaust Option(s) | N/A |
| Plant Duct Static Pressure Inches (mm) | 0.05-0.1"/1.27-2.54mm H2O |
| Australian Test Method | N/A |
| Performance Standard | NSF-ANSI-49 |
| Safety Certification |
| Air Cleanliness (ISO 14644) | ISO-Class-5 |
| Downflow fpm (m/s) | 60 fpm (0.30 m/s) |
| Fumigation: per NIH/NSF Procedures | True |
| Inflow fpm (m/s) | 105 fpm (0.53 m/s) |
| Protection | Product, Personnel, Environmental |
| Airflow Monitor | Pressure |
| Control System | AeroMax |
| Est. Shipping Weight lbs (kg) | 865 (392) |
| Net Weight lbs (kg) | 815 (369) |
| Blower Contact Wires | N/A |
| Closure Panels | N/A |
| Cord Pass Through | N/A |
| Double Exhaust HEPA Filter | N/A |
| Gas Supply Interlock with Blower | N/A |
| Glass Sidewalls | N/A |
| IV Bar with 6 Hooks | N/A |
| Magnifying Glass in Window | Optional |
| Motorized Base Stand | Included |
| Motorized Window | N/A |
| Other Built-in Supply Filter Option(s) | N/A |
| Outlet(s) | Standard, two backwall |
| Plumbing | N/A |
| Remote Service Valves | N/A |
| Seismic Brackets or Studs | N/A |
| Service Couplings (3/8-inch NPT) | None, Maximum of Two Each Side Wall Optional |
| Service Valves (3/8-inch NPT) | None, Maximum of Two Each Side Wall Optional |
| Side Panels | N/A |
| Smooth Interior | N/A |
| Ultraviolet (UV) Light | Optional |
| Window Edge Protector | Optional |
| Access Opening Glass Type | Tempered Glass |
| Armrest | Standard Plastic with Optional Stainless Steel |
| Cabinet Construction | All welded stainless steel 16/18 GA, Type 304 pressure tight design |
| Casters | 5" (13mm) Casters Standard |
| Decontamination Seal-able Window | N/A |
| Diffuser | Metal, non-flammable |
| Drain Valve Location | Front right |
| Exhaust Filter | 11 1/2-inch (292 mm) 99.99% Efficiency @ 0.3 Micron |
| Front & Control Panel Material | Painted Steel |
| HEPA Filter Seal Type | HEPEX Zero Leak Neoprene Seal, Spring-loaded |
| Lighting | LED |
| Main Cabinet Wrap | Single Piece Stainless Steel Side and Back Wall Construction |
| Motor(s) | 1 HP DC ECM |
| Plenum Type | HEPEX |
| Pre-filter | Behind Back Wall |
| Style | Low profile console integral auto-adjustable base stand |
| Supply Filter | 3-inch (76mm) 99.99% Efficiency @ 0.3 Micron |
| Viewing Window Inches (mm) | 21 (533) open to fully closed |
| Work Access Opening(s) | 12-inch (305mm) |
| Work Surface | One-Piece Flat Stainless Steel with Prop-Up Rod |
| Work Zone Wrap | Single Piece Stainless Steel Side and Back Wall Construction |
| Data Output Features | RS-232 |
| Remote Alarm Terminals | Standard |
| Est. Shipping Depth Inches (mm) | 43 (1092) |
| Est. Shipping Height Inches (mm) | 75 (1905) |
| Est. Shipping Width Inches (mm) | 70 (1778) |
| Exterior Depth Inches (mm) | 32 1/8 (817) |
| Exterior Depth with Armrest Removed Inches (mm) | 31 3/8 (797) |
| Exterior Height (Minimum for Transport) Inches (mm) | 79 1/2 (2020) |
| Exterior Height Inches (mm) | 81 (2058)-99 1/2 (2527) |
| Exterior Height with 30-inch (762 mm) Work Surface Height inches (mm) | 81 (2058) with 24 1/2 inch (622 mm) Work Surface Height |
| Exterior Height with 36-inch (915 mm) Work Surface Height inches (mm) | 99 1/2 (2527) with 43 inch (1092 mm) Work Surface Height |
| Exterior Width Inches (mm) | 65 1/2 (1663) |
| Nominal Width Feet (Meters) | 5 ft. (1.5m) |
| Useable Work Tray Area Depth Inches (mm) | 21 3/4 (552) |
| Useable Work Tray Area Width Inches (mm) | 58 (1473) |
| Work Area Depth Measured at 10-inches (254 mm) Window Height Inches (mm) | N/A |
| Work Area Depth Measured at 12-inches (305 mm) Window Height Inches (mm) | 25 1/2 (642) |
| Work Area Depth Measured at 14-inches (356 mm) Window Height Inches (mm) | N/A |
| Work Area Depth Measured at 8-inches (203 mm) Window Height Inches (mm) | N/A |
| Work Area Height Inches (mm) | 28 1/2 (724mm) |
| Work Area Width Inches (mm) | 58 3/8 (1483) |
| Blower/Lights Amps [10-inch (254 mm) Access Opening] | |
| Blower/Lights Amps [12-inch (305 mm) Access Opening] | 5.5 |
| Blower/Lights Amps [14-inch (356mm) Access Opening] | |
| Blower/Lights Amps [8-inch (203 mm) Access Opening] | |
| Electrical Configuration | 230V5060Hz |
| Junction Box | N/A |
| Outlet Amps | 3 |
| Power Cord | 12 ft., 16A |
| Power Cord Length Foot (Meter) | 12 (3.7) |
| Rated Amps | 11 |
| Light Intensity fc (Lux) | 90-120 (968-1291) |
| Reach into workzone Inches (mm) | 6 (152) |
| Sound Pressure Level per ISO 4871 | ≤ 60 dbA |
| 10-inch (254 mm) Opening Exhaust Requirement for Fixed Canopy (NU-907/NU-916) CFM (CMH) | N/A |
| 10-inch (254 mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM (CMH) | N/A |
| 12-inch (305 mm) Opening Exhaust Requirement for Fixed Canopy (NU-907/NU-916) CFM (CMH) | 659 (1120) |
| 12-inch (305 mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM (CMH) | 611-761 (1038-1294) |
| 14-inch (356mm) Opening Exhaust Requirement for Fixed Canopy (NU-926) CFM(CMH) | N/A |
| 14-inch (356mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM(CMH) | N/A |
| 8-inch (203 mm) Opening Exhaust Requirement for Fixed Canopy (NU-907/NU-916) CFM (CMH) | N/A |
| 8-inch (203 mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM (CMH) | N/A |
| Bag In Bag Out | N/A |
| Heat Rejected 10-inch (254 mm) Access Opening (BTU/Hour) | N/A |
| Heat Rejected 12-inch (305 mm) Access Opening (BTU/Hour) | Inquire |
| Heat Rejected 14-inch (356 mm) Access Opening (BTU/Hour) | N/A |
| Heat Rejected 8-inch (203 mm) Access Opening (BTU/Hour) | N/A |
| Heat Rejected Vented (BTU/Hour) | Inquire |
| Other Built-in Exhaust Option(s) | N/A |
| Plant Duct Static Pressure Inches (mm) | 0.05-0.1"/1.27-2.54mm H2O |
| Australian Test Method | N/A |
| Performance Standard | |
| Safety Certification |
| Air Cleanliness (ISO 14644) | ISO-Class-5 |
| Downflow fpm (m/s) | 60 fpm (0.30 m/s) |
| Fumigation: per NIH/NSF Procedures | True |
| Inflow fpm (m/s) | 105 fpm (0.53 m/s) |
| Protection | Product, Personnel, Environmental |
| Airflow Monitor | Pressure |
| Control System | AeroMax |
| Est. Shipping Weight lbs (kg) | 865 (392) |
| Net Weight lbs (kg) | 815 (369) |
| Blower Contact Wires | N/A |
| Closure Panels | N/A |
| Cord Pass Through | N/A |
| Double Exhaust HEPA Filter | N/A |
| Gas Supply Interlock with Blower | N/A |
| Glass Sidewalls | N/A |
| IV Bar with 6 Hooks | N/A |
| Magnifying Glass in Window | Optional |
| Motorized Base Stand | Included |
| Motorized Window | N/A |
| Other Built-in Supply Filter Option(s) | N/A |
| Outlet(s) | Standard, two backwall |
| Plumbing | N/A |
| Remote Service Valves | N/A |
| Seismic Brackets or Studs | N/A |
| Service Couplings (3/8-inch NPT) | None, Maximum of Two Each Side Wall Optional |
| Service Valves (3/8-inch NPT) | None, Maximum of Two Each Side Wall Optional |
| Side Panels | N/A |
| Smooth Interior | N/A |
| Ultraviolet (UV) Light | Optional |
| Window Edge Protector | Optional |
| Access Opening Glass Type | Tempered Glass |
| Armrest | Standard Plastic with Optional Stainless Steel |
| Cabinet Construction | All welded stainless steel 16/18 GA, Type 304 pressure tight design |
| Casters | 5" (13mm) Casters Standard |
| Decontamination Seal-able Window | N/A |
| Diffuser | Metal, non-flammable |
| Drain Valve Location | Front right |
| Exhaust Filter | 11 1/2-inch (292 mm) 99.99% Efficiency @ 0.3 Micron |
| Front & Control Panel Material | Painted Steel |
| HEPA Filter Seal Type | HEPEX Zero Leak Neoprene Seal, Spring-loaded |
| Lighting | LED |
| Main Cabinet Wrap | Single Piece Stainless Steel Side and Back Wall Construction |
| Motor(s) | 1 HP DC ECM |
| Plenum Type | HEPEX |
| Pre-filter | Behind Back Wall |
| Style | Low profile console integral auto-adjustable base stand |
| Supply Filter | 3-inch (76mm) 99.99% Efficiency @ 0.3 Micron |
| Viewing Window Inches (mm) | 21 (533) open to fully closed |
| Work Access Opening(s) | 12-inch (305mm) |
| Work Surface | One-Piece Flat Stainless Steel with Prop-Up Rod |
| Work Zone Wrap | Single Piece Stainless Steel Side and Back Wall Construction |
| Data Output Features | RS-232 |
| Remote Alarm Terminals | Standard |
| Est. Shipping Depth Inches (mm) | 43 (1092) |
| Est. Shipping Height Inches (mm) | 86 (2184) |
| Est. Shipping Width Inches (mm) | 84 (2134) |
| Exterior Depth Inches (mm) | 32 1/8 (817) |
| Exterior Depth with Armrest Removed Inches (mm) | 31 3/8 (797) |
| Exterior Height (Minimum for Transport) Inches (mm) | 79 1/2 (2020) |
| Exterior Height Inches (mm) | 81 (2058)-99 1/2 (2527) |
| Exterior Height with 30-inch (762 mm) Work Surface Height inches (mm) | 81 (2058) with 24 1/2 inch (622 mm) Work Surface Height |
| Exterior Height with 36-inch (915 mm) Work Surface Height inches (mm) | 99 1/2 (2527) with 43 inch (1092 mm) Work Surface Height |
| Exterior Width Inches (mm) | 77 1/2 (1968) |
| Nominal Width Feet (Meters) | 6 ft. (1.8m) |
| Useable Work Tray Area Depth Inches (mm) | 21 3/4 (552) |
| Useable Work Tray Area Width Inches (mm) | 70 (1783) |
| Work Area Depth Measured at 10-inches (254 mm) Window Height Inches (mm) | N/A |
| Work Area Depth Measured at 12-inches (305 mm) Window Height Inches (mm) | 25 1/2 (642) |
| Work Area Depth Measured at 14-inches (356 mm) Window Height Inches (mm) | N/A |
| Work Area Depth Measured at 8-inches (203 mm) Window Height Inches (mm) | N/A |
| Work Area Height Inches (mm) | 28 1/2 (724mm) |
| Work Area Width Inches (mm) | 70 3/8 (1788) |
| Blower/Lights Amps [10-inch (254 mm) Access Opening] | |
| Blower/Lights Amps [12-inch (305 mm) Access Opening] | 7.1 |
| Blower/Lights Amps [14-inch (356mm) Access Opening] | |
| Blower/Lights Amps [8-inch (203 mm) Access Opening] | |
| Electrical Configuration | 115V60Hz |
| Junction Box | N/A |
| Outlet Amps | 3 |
| Power Cord | 12 ft. 12 GA-3 Wire, 20A |
| Power Cord Length Foot (Meter) | 12 (3.7) |
| Rated Amps | 16 |
| Light Intensity fc (Lux) | 90-120 (968-1291) |
| Reach into workzone Inches (mm) | 6 (152) |
| Sound Pressure Level per ISO 4871 | ≤ 62 dbA |
| 10-inch (254 mm) Opening Exhaust Requirement for Fixed Canopy (NU-907/NU-916) CFM (CMH) | N/A |
| 10-inch (254 mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM (CMH) | N/A |
| 12-inch (305 mm) Opening Exhaust Requirement for Fixed Canopy (NU-907/NU-916) CFM (CMH) | 786 (1336) |
| 12-inch (305 mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM (CMH) | 756-866 (1285-1473) |
| 14-inch (356mm) Opening Exhaust Requirement for Fixed Canopy (NU-926) CFM(CMH) | N/A |
| 14-inch (356mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM(CMH) | N/A |
| 8-inch (203 mm) Opening Exhaust Requirement for Fixed Canopy (NU-907/NU-916) CFM (CMH) | N/A |
| 8-inch (203 mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM (CMH) | N/A |
| Bag In Bag Out | N/A |
| Heat Rejected 10-inch (254 mm) Access Opening (BTU/Hour) | N/A |
| Heat Rejected 12-inch (305 mm) Access Opening (BTU/Hour) | 2787 |
| Heat Rejected 14-inch (356 mm) Access Opening (BTU/Hour) | N/A |
| Heat Rejected 8-inch (203 mm) Access Opening (BTU/Hour) | N/A |
| Heat Rejected Vented (BTU/Hour) | 198 |
| Other Built-in Exhaust Option(s) | N/A |
| Plant Duct Static Pressure Inches (mm) | 0.05-0.1"/1.27-2.54mm H2O |
| Australian Test Method | N/A |
| Performance Standard | NSF-ANSI-49 |
| Safety Certification |
| Air Cleanliness (ISO 14644) | ISO-Class-5 |
| Downflow fpm (m/s) | 60 fpm (0.30 m/s) |
| Fumigation: per NIH/NSF Procedures | True |
| Inflow fpm (m/s) | 105 fpm (0.53 m/s) |
| Protection | Product, Personnel, Environmental |
| Airflow Monitor | Pressure |
| Control System | AeroMax |
| Est. Shipping Weight lbs (kg) | 930 (421) |
| Net Weight lbs (kg) | 880 (398) |
| Blower Contact Wires | N/A |
| Closure Panels | N/A |
| Cord Pass Through | N/A |
| Double Exhaust HEPA Filter | N/A |
| Gas Supply Interlock with Blower | N/A |
| Glass Sidewalls | N/A |
| IV Bar with 6 Hooks | N/A |
| Magnifying Glass in Window | Optional |
| Motorized Base Stand | Included |
| Motorized Window | N/A |
| Other Built-in Supply Filter Option(s) | N/A |
| Outlet(s) | Standard, two backwall |
| Plumbing | N/A |
| Remote Service Valves | N/A |
| Seismic Brackets or Studs | N/A |
| Service Couplings (3/8-inch NPT) | None, Maximum of Two Each Side Wall Optional |
| Service Valves (3/8-inch NPT) | None, Maximum of Two Each Side Wall Optional |
| Side Panels | N/A |
| Smooth Interior | N/A |
| Ultraviolet (UV) Light | Optional |
| Window Edge Protector | Optional |
| Access Opening Glass Type | Tempered Glass |
| Armrest | Standard Plastic with Optional Stainless Steel |
| Cabinet Construction | All welded stainless steel 16/18 GA, Type 304 pressure tight design |
| Casters | 5" (13mm) Casters Standard |
| Decontamination Seal-able Window | N/A |
| Diffuser | Metal, non-flammable |
| Drain Valve Location | Front right |
| Exhaust Filter | 11 1/2-inch (292 mm) 99.99% Efficiency @ 0.3 Micron |
| Front & Control Panel Material | Painted Steel |
| HEPA Filter Seal Type | HEPEX Zero Leak Neoprene Seal, Spring-loaded |
| Lighting | LED |
| Main Cabinet Wrap | Single Piece Stainless Steel Side and Back Wall Construction |
| Motor(s) | 1 HP DC ECM |
| Plenum Type | HEPEX |
| Pre-filter | Behind Back Wall |
| Style | Low profile console integral auto-adjustable base stand |
| Supply Filter | 3-inch (76mm) 99.99% Efficiency @ 0.3 Micron |
| Viewing Window Inches (mm) | 21 (533) open to fully closed |
| Work Access Opening(s) | 12-inch (305mm) |
| Work Surface | One-Piece Flat Stainless Steel with Prop-Up Rod |
| Work Zone Wrap | Single Piece Stainless Steel Side and Back Wall Construction |
| Data Output Features | RS-232 |
| Remote Alarm Terminals | Standard |
| Est. Shipping Depth Inches (mm) | 43 (1092) |
| Est. Shipping Height Inches (mm) | 86 (2184) |
| Est. Shipping Width Inches (mm) | 84 (2134) |
| Exterior Depth Inches (mm) | 32 1/8 (817) |
| Exterior Depth with Armrest Removed Inches (mm) | 31 3/8 (797) |
| Exterior Height (Minimum for Transport) Inches (mm) | 79 1/2 (2020) |
| Exterior Height Inches (mm) | 81 (2058)-99 1/2 (2527) |
| Exterior Height with 30-inch (762 mm) Work Surface Height inches (mm) | 81 (2058) with 24 1/2 inch (622 mm) Work Surface Height |
| Exterior Height with 36-inch (915 mm) Work Surface Height inches (mm) | 99 1/2 (2527) with 43 inch (1092 mm) Work Surface Height |
| Exterior Width Inches (mm) | 77 1/2 (1968) |
| Nominal Width Feet (Meters) | 6 ft. (1.8m) |
| Useable Work Tray Area Depth Inches (mm) | 21 3/4 (552) |
| Useable Work Tray Area Width Inches (mm) | 70 (1783) |
| Work Area Depth Measured at 10-inches (254 mm) Window Height Inches (mm) | N/A |
| Work Area Depth Measured at 12-inches (305 mm) Window Height Inches (mm) | 25 1/2 (642) |
| Work Area Depth Measured at 14-inches (356 mm) Window Height Inches (mm) | N/A |
| Work Area Depth Measured at 8-inches (203 mm) Window Height Inches (mm) | N/A |
| Work Area Height Inches (mm) | 28 1/2 (724mm) |
| Work Area Width Inches (mm) | 70 3/8 (1788) |
| Blower/Lights Amps [10-inch (254 mm) Access Opening] | |
| Blower/Lights Amps [12-inch (305 mm) Access Opening] | 5.8 |
| Blower/Lights Amps [14-inch (356mm) Access Opening] | |
| Blower/Lights Amps [8-inch (203 mm) Access Opening] | |
| Electrical Configuration | 230V5060Hz |
| Junction Box | N/A |
| Outlet Amps | 3 |
| Power Cord | 12 ft., 16A |
| Power Cord Length Foot (Meter) | 12 (3.7) |
| Rated Amps | 11 |
| Light Intensity fc (Lux) | 90-120 (968-1291) |
| Reach into workzone Inches (mm) | 6 (152) |
| Sound Pressure Level per ISO 4871 | ≤ 62 dbA |
| 10-inch (254 mm) Opening Exhaust Requirement for Fixed Canopy (NU-907/NU-916) CFM (CMH) | N/A |
| 10-inch (254 mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM (CMH) | N/A |
| 12-inch (305 mm) Opening Exhaust Requirement for Fixed Canopy (NU-907/NU-916) CFM (CMH) | 786 (1336) |
| 12-inch (305 mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM (CMH) | 756-866 (1285-1473) |
| 14-inch (356mm) Opening Exhaust Requirement for Fixed Canopy (NU-926) CFM(CMH) | N/A |
| 14-inch (356mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM(CMH) | N/A |
| 8-inch (203 mm) Opening Exhaust Requirement for Fixed Canopy (NU-907/NU-916) CFM (CMH) | N/A |
| 8-inch (203 mm) Opening Exhaust Requirement for Variable Flow Canopy (NU-911) CFM (CMH) | N/A |
| Bag In Bag Out | N/A |
| Heat Rejected 10-inch (254 mm) Access Opening (BTU/Hour) | N/A |
| Heat Rejected 12-inch (305 mm) Access Opening (BTU/Hour) | Inquire |
| Heat Rejected 14-inch (356 mm) Access Opening (BTU/Hour) | N/A |
| Heat Rejected 8-inch (203 mm) Access Opening (BTU/Hour) | N/A |
| Heat Rejected Vented (BTU/Hour) | Inquire |
| Other Built-in Exhaust Option(s) | N/A |
| Plant Duct Static Pressure Inches (mm) | 0.05-0.1"/1.27-2.54mm H2O |
| Australian Test Method | N/A |
| Performance Standard | |
| Safety Certification |
| Air Cleanliness (ISO 14644) | ISO-Class-5 |
| Downflow fpm (m/s) | 60 fpm (0.30 m/s) |
| Fumigation: per NIH/NSF Procedures | True |
| Inflow fpm (m/s) | 105 fpm (0.53 m/s) |
| Protection | Product, Personnel, Environmental |
| Airflow Monitor | Pressure |
| Control System | AeroMax |
| Est. Shipping Weight lbs (kg) | 930 (421) |
| Net Weight lbs (kg) | 880 (398) |
Review
Resources
Brochures
Manuals
Drawings
Specifications
Request Your Quote for a NU-677
Please fill out the form below for a lab equipment quote and we'll get to work on getting you what you need. Need to talk with someone right away? Give us a call at 763-553-1270.
Thank you for completing the form.
We will be in touch. If you have any urgent questions, please reach out at 763-553-1270.
